FOTON 6T Wrecker Truck For Sale

FOTON 6T Wrecker Truck For Sale
FOTON 6T Wrecker Truck For Sale
FOTON 6T Wrecker Truck For Sale
1 / 3
FOTON 6T Wrecker Truck For Sale
FOTON 6T Wrecker Truck For Sale
FOTON 6T Wrecker Truck For Sale
Configuration Item Specification
1. Chassis Configuration
Cab Type Foton Aumark crew cab with forward-tilting function
Wheelbase 4700mm
Engine Cummins 220 horsepower engine
Gearbox Shaanxi Fast 8-speed gearbox
Tires 8.25R20 tires
Front Axle 4.6T front axle
Rear Axle 9T rear axle with 4.875 speed ratio
Leaf Spring Quantity 3/10+8 leaf springs
Gross Vehicle Weight 14055kg
Fuel Tank 200L aluminum alloy fuel tank
Standard Factory Components Original factory power take-off (PTO), original factory 3-layer through beam
Steering Wheel Multi-function steering wheel
Instrument Cluster LCD instrument cluster
Other Configurations The rest are in accordance with the standard chassis configuration
2. Upper Mounting Configuration
Upper Mounting Type One-tow-two upper mounting structure
Manufacturing Process Sunken upper mounting process (to lower the center of gravity of the flatbed)
Flatbed Dimensions Total length: approx. 6.5m, width: 2.55m
Tail Flip Length 1.2m tail flip section
Flatbed Material Made of 5mm wear-resistant checkered plate
Frame 14mm solid steel plate frame with cut holes
Tail Hinges Tail through-shaft detachable flip hinges
Slide Rails 10mm manganese steel slide rails (reinforced with 8mm steel plate bound outside the flared opening)
Under-Plate Reinforcement Dense grid-shaped reinforcement under the plate, dense triangular diagonal bracing
Winch 6-ton winch
Rear Support Arm 6-ton rear support arm
Hydraulic Valve Zhongmei hydraulic multi-way valve
Oil Cylinders 110-type flatbed telescopic oil cylinder, 110-type lifting oil cylinder
3. On-board Accessories
Gantry Side Lights 1 set of gantry side lights
Rear LED Work Lights 2 rear LED work lights
Lashing Straps 4 lashing straps
Triangular Tire Stoppers 1 pair of triangular tire stoppers
Square Tire Holding Tubes 1 pair of square tire holding tubes
L-shaped Forks 1 pair of L-shaped forks
Tool Box 1 tool box
