Item Specification
1. CHASSIS BASIC PARAMETERS
Chassis Brand & Model Mercedes-Benz Actros 6x4
Drive Type 6×4 Rear Double Axle Drive
Cab Type Double Row 4-door Crew Cab, 6 Seats Total
Wheelbase 3800 + 1450 mm
Overall Dimension (L×W×H) 10200 × 2500 × 3480 mm
Tire Specification 12.00R20 Heavy Duty Radial Tire, 10 pcs
Transmission Gearbox Automatic Transmission
Steering System Hydraulic Power Steering
Brake System Full Air Brake with ABS & ASR Anti-slip System
Max Travel Speed 95 km/h
Emission Standard Euro VI
2. ENGINE PARAMETERS
Engine Model Mercedes-Benz OM470LA
Fuel Type Diesel
Rated Power 350 kW / 476 HP
Displacement 12.8 L
Intake Mode Turbocharged & Intercooled
Cooling Mode Water Cooling
3. VEHICLE WEIGHT & LOAD CAPACITY
Gross Vehicle Weight (GVW) 32000 kg
Curb Weight 14000 kg
Rated Liquid Loading Capacity 18000 kg
Front Overhang 1500 mm
Rear Overhang 2450 mm
4. TANK & LIQUID CAPACITY
Water Tank Volume 15000 L
Foam Tank Volume 3000 L
Total Liquid Capacity 18000 L
Water Tank Material High-strength Carbon Steel with Full Anti-corrosion & Anti-rust Treatment
Foam Tank Material 304 Food Grade Stainless Steel
Tank Structure Built-in Wave Baffles, Reinforced Tank Body, Float-type Liquid Level Indicator
Tank Thickness 5mm Tank Body, 6mm Tank Head
Drain Valve 3-inch Stainless Steel Ball Valve
Manhole 500mm Diameter Sealed Manhole with Access Ladder
5. FIRE FIGHTING CORE PERFORMANCE
Fire Pump Model Medium & Low Pressure Dual-purpose Fire Pump
Rated Pump Flow 50 L/s
Rated Working Pressure 1.0 MPa
Suction Depth ≥ 7 m
Self-priming Time ≤ 25 s
Fire Monitor PL40 Water & Foam Dual-purpose Cannon
Rated Monitor Flow 40 L/s
Water Jet Range ≥ 65 m
Foam Jet Range ≥ 55 m
Monitor Rotation 360° Horizontal Rotation, -30° ~ +70° Vertical Pitch
Power Take-off (PTO) Full Power Sandwich PTO
Foam Proportioning System Automatic & Manual Dual Control Mixing System
6. STANDARD EQUIPMENT
Fire Fighting Accessories Full set of fire hoses, suction pipes, quick couplings, spray nozzles & fire hydrant connectors
Warning & Lighting System Roof red long row warning light, high-decibel 100W alarm siren, LED search working lamp & internal compartment lighting
Compartment Structure Full aluminum alloy equipment compartments with lockable doors, independent pump room
Safety Protection Devices Emergency stop device, pump overload protection, pressure relief safety valve, anti-freeze device
Rescue Hand Tools Complete fire rescue hand tools, fire axe, crowbar, fire spade, 6m fire ladder
Pump Control System In-cab + Pump Room Dual Control System, water circulation cooling system for pump operation
Pump System Accessories Water filter, check valve, high-precision pressure gauge & flow meter
7. CERTIFICATION & AFTER-SALES TERMS
Main Certificates CE, ISO9001, CCC, Vehicle Official Road Announcement Certificate
Warranty Period 12 months or 20,000 km from delivery date (whichever comes first)
Standard Production Lead Time 20–25 working days
Standard Loading Port Shanghai Port / Wuhan Port, China
Optional Upgrade Items Imported fire pump, wireless remote monitor control, fully automatic foam mixing system, thermal imaging camera
